ETD34 6+6 Pin Vertical High Frequency Transformer
YINDATE MAGNETIC COMPONENTS
ETD34 Transformer
This ETD34 transformer uses a vertical 6+6 pin configuration. The catalog shows two views of the same product format to help buyers review its winding and terminal arrangement.
Technical Specifications
| Model | ETD34 |
|---|---|
| Product family | EER / ETD Transformers |
| Mounting orientation | Vertical |
| Pin arrangement | 6+6 pins |
| Catalog pin pitch | 5.0 mm |
| Catalog row spacing | 12.4 mm |
| Catalog power reference | ≥ 145 W |
| Catalog frequency range | 20-500 kHz |
Catalog values are preliminary selection references. Final electrical ratings, temperature rise, insulation and mounting dimensions must be confirmed against the approved drawing for your application.
Applications
The catalog lists LED power supplies, inverters and switching power supplies as application areas. Suitability depends on the selected winding design and operating conditions.
Custom Manufacturing
Shenzhen Yindate Electronic Co., Ltd. develops magnetic components to customer drawings, samples and electrical requirements. Send your input and output voltage, operating frequency, circuit topology, winding or turns-ratio requirements, insulation requirements, and PCB footprint for a specification review.
Sample evaluation and production planning follow the agreed specification. Request a quotation with your target quantity and delivery schedule.
Engineering & Ordering Information
Can I request a drawing or datasheet?
Product specifications and electrical drawings can be provided for review. Identify the model and your required configuration in the inquiry.
What are the MOQ and lead time?
MOQ and delivery depend on the structure, materials and order quantity. Please request confirmation for your project.
Are special compliance requirements available?
List the applicable requirements in your inquiry so the relevant material reports, testing scope and certification support can be confirmed for the proposed construction.
Request a Project Quotation
Reference ETD34 and include your drawing or sample, electrical requirements and expected quantity. Our team can review the specification before sampling.
Discuss your application
Share the required electrical parameters, pin arrangement, mounting dimensions, quantity and application. Final specifications are confirmed after technical review.
Samples and production
Sample timing, MOQ, production lead time and shipping terms are quoted for each project. Please validate samples in your application before production approval.
